background image

Page 2-10

Section 2. Configuration

SATO CL408e/CL412e Service Manual

PN 9001078

Rev. B

There are five Speed settings on the printer. The setting is listed on the bottom line

of the display. The current setting is indicated by an underline under one of the

speed settings. To change the setting:

STEP

PROCEDURE

1.

Use the LINE key to step the underlined cursor to the desired

speed setting.

2 = 2 in/s (50mm/s)

3 = 3 in/s (75mm/s)

4 = 4 in/s (100mm/s)

5 = 5 in/s (125mm/s)

6 = 6 in/s (150mm/s)

2.

Once the correct setting is underlined, press the FEED key to

accept the setting and advance to the next adjustment.

Print Speed Adjustment

PRINT speed

2 3 4 5 6

The label pitch is the distance from the leading edge (the edge that comes out of the

printer first) of a label and the leading edge of the next label. The leading edge position of

the label can be adjusted relative to the print head +/- 49mm in increments of 1mm.

Once the position is set, it can be fine adjusted +/- 3.75mm using the PITCH

potentiometer on the adjustment panel.

Pitch Offset Adjustment

pitch offset

+00mm

STEP

PROCEDURE

1.

The underline cursor will initially be positioned underneath the Pitch

Direction setting. Use the LINE key to step the underline to either the

positive (+) or negative (-) selection. A position selection moves the

leading edge of the label forward (away from the print head) while a

negative selection moves the leading edge of the label back into the

mechansim.

2.

Once the correct setting is underlined, press the FEED key to

accept the setting and advance to the Offset adjustment.

3.

Use the LINE Key to step the first digit of the counter to the desired setting.

The display will increment one step each time the LINE key is pressed. The

reading will advance to a setting of 4 after which it will automatically wrap

and start at 0 again.

LCD Panel — Normal Mode
