Section 2. Configuration
SATO CL408e/CL412e Service Manual PN 9001078
Rev. B
This display will only appear when Backfeed is enabled (DSW3-4 = OFF). The maximum
backfeed distance is 255mm.
Forward/Backfeed
Distance
Default
STEP PROCEDURE
1. Press the FEED key to use the default distance. This setting will be
appropriate for use with standard labels with a 1/8" gap between labels
and most tag stock applications.
2. Press the LINE key to set your own backfeed distance up to 255mm.
Each time you press the LINE key, the distance is advanced 1mm.
CAUTION: A backfeed distance over 40mm may cause ribbon wrinkle
and require ribbon tension adjustments.
3. Press the FEED key to accept the selected backfeed distance.
forward/backfeed
distance default
LCD Panel — Service Mode
forward/backfeed
distance XXXmm
This selection allows user selection of when Pin #9 of the 14 pin EXT connector goes
HIGH, to allow printer status to be determined without using Bi-Directional
Communication Select Mode1 or Mod2, using the Line key. Press FEED key to save and
exit.
MODE 1 = On-Line print job waiting.
MODE 2 = On-Line
EXt pin9 select
mode 1 mode2
Ext Port
Pin 9 Select
