Page 2-9
Section 2. Configuration
SATO CL408e/CL412e Service Manual PN 9001078
Rev. B
LCD Panel — Normal Mode
When the printer is first powered on it displays the current ROM version of the printer
then immediately displays the ONLINE mode.
The LCD Panel will display the ONLINE status on the top line of the display. The bottom
line will contain the label quantity (QTY) status. The message will be changed to
OFFLINE whenever the printer is switched offline by depressing the LINE key. As soon as
a print job is received, the QTY message will indicate the number of labels to be printed.
As soon as the label job begins to print, the display will indicate the number of labels
remaining in the print job that remain to be printed. The user can access the User
Settings using the following procedures.
User Settings
STEP PROCEDURE
1. The printer is first taken offline by pressing the LINE key once.
The display will change to OFFLINE.
2. Press the LINEand FEED keys simultaneously for more than one
second. The printer now displays the first USER mode
adjustment (Print Darkness).
There are five Darkness (or heat range) settings on the printer. The higher
numbers represent darker settings. The current setting is indicated by a line under
one of the range settings.
To change the setting perform the following steps:
STEP PROCEDURE
1. Use the LINE key to step the underlined cursor to the desired
setting.
2. Once the correct setting is underlined, press the FEED key to
accept the setting and advance to the next adjustment.
OFFLINE
000000
Print Darkness Setting
PRINT DARKNESS
1 2 3 4 5
1 = Light
2 = Slightly Light
3 = Medium
4 = Slightly Dark
5 = Dark
ONLINE
QTY: 000000
initializing
rom v0.00.00.00
