Section 2. Configuration
SATO CL408e/CL412e Service Manual
PN 9001078
Rev. B
2.3 LCD Panel Configuration
The LCD Panel on the CL408e/CL412e is used in conjunction with the LINE and FEED
switches by the operator to manually enter printer configuration settings. Many of the
settings can also be controlled via software commands and in the case of conflict between
software and control panel settings, the printer will always use the last valid setting. If you
load a label job that includes software settings and then enter a new setting via the LCD
Panel, the manually set values will be used by the printer. If you set the values manually
and then download a job with software settings, the software settings will be used.
There are 7 configuration and operation modes you can access from the LCD panel. To
enter the desired mode, the KEY SEQUENCE combination listed in the table below must be
performed. The initial LCD display message is shown for each mode.
