– 6 –
SM830078
(1)
Unit Specifications
2. SPECIFICATIONS
MODEL No.
Indoor Unit
XS4232
Outdoor Unit
C4232
POWER SOURCE
230 - 208 V / 1 Phase / 60 Hz
PERFORMANCE
Cooling
Capacity
BTU / h
42,000
40,500
kW
12.32
11.88
Air circulation (Hi)
cu.ft. / min.
980
880
Moisture removal (High)
Pints / h
14.6
14.8
ELECTRICAL RATINGS
Voltage rating
VAC
230
208
Available voltage range
VAC
187 - 253
Running amperes*
A
20.8
21.1
Max. running amperes**
A
24.1
25.3
Power input
W
4,230
4,120
Power factor
%
88
94
S.E.E.R
BTU / Wh
10.2
10.3
Max. starting amperes
A
134
134
Maximum fuse size
A
50
FEATURES
Controls
Microprocessor
Timer
ON / OFF 24-hours & Program
Fan speed Indoor / Outdoor
3 and Automatic control / 2 (Auto)
Air deflection
Horizontal / Vertical
– / Automatic
Air filter
Washable, easy access, long life (2,500 hr)
Remote controller (Accessory)
RCS - 5PS4U
Refrigerant control
Capillary tube
Refrigerant tubing connections
Flare type
Drain pump / Drain pipe trade size
Max. head 9-27/32 in. above drain connection / 3/4 in. (26.7 mm)
Compressor
Scroll
Operation sound
Indoor - Hi / Me / Lo
dB - A
43 / 40 / 36
Outdoor - Hi
dB - A
56
REFRIGERANT TUBING
Limit of tubing length
ft.
(m)
165 (50)
Limit of tubing length at shipment
ft.
(m)
50 (15)
Limit of elevation difference
ft.
(m)
Outdoor unit is higher than indoor unit: 165 (50)
between the two units
Outdoor unit is lower than indoor unit: 100 (30)
Refrigerant tube
Narrow tube
in. (mm)
3 / 8 (9.52)
outer diameter
Wide tube
in. (mm)
3 / 4 (19.05)
Refrigerant amount at shipment
lbs. (kg)
R22 : 9.7 (4.4)
DIMENSIONS & WEIGHT
Indoor unit
Outdoor unit
Unit dimensions
Height
in. (mm)
11-1/32
(280)
48-5/8
(1,235)
Width
in. (mm)
41-11/32
(1,050)
37
(940)
Depth
in. (mm)
29-29/32
(760)
13-3/8
(340)
Net weight
lbs. (kg)
60
(27)
205
(93)
Indoor grille dimensions
Height
in. (mm)
3-1/16
(78)
–
Width
in. (mm)
45-9/32
(1,150)
–
Depth
in. (mm)
33-27/32
(860)
–
Net weight
lbs. (kg)
15
(7)
–
Indoor Unit
Height
in. (mm)
12-7/16
(316)
52-7/32
(1,326)
Package dimensions
Width
in. (mm)
43-27/32
(1,114)
40
(1,016)
Depth
in. (mm)
32-25/32
(833)
16-3/8
(416)
Shipping weight
lbs. (kg)
71
(32)
229
(104)
Shipping volume
cu. ft. (m
3
)
10.3
(0.293)
19.8
(0.56)
Indoor grille
Height
in. (mm)
4-3/32
(104)
–
Package dimensions
Width
in. (mm)
49-1/2
(1,257)
–
Depth
in. (mm)
39-11/32
(999)
–
Shipping weight
lbs. (kg)
29
(10)
–
Shipping volume
cu. ft. (m
3
)
4.6
(0.131)
–
Cooling :
Rating conditions (*)
: Indoor air temperature 80
°
F DB / 67
°
F WB, Outdoor air temperature 95
°
F DB / 75
°
F WB
Full load conditions (**)
: Indoor air temperature 80
°
F DB / 67
°
F WB, Outdoor air temperature 115
°
F DB
DATA SUBJECT TO CHANGE WITHOUT NOTICE
