Page 29
– 29 –
SM830078
5. PERFORMANCE CHARTS
(2)
High and Low Pressure
1
1
1
1
1
Indoor Unit: XS4232, TS4232
Outdoor Unit: C4232
• High Pressure
High pressure characteristics versus outdoor ambient temperature and indoor temperature.
(Indoor relative humidity: 50%, Indoor fan speed: High)
230V / 208V
• Low Pressure
Low pressure characteristics versus outdoor ambient temperature and indoor temperature.
(Indoor relative humidity: 50%, Indoor fan speed: High)
230V / 208V
1442_X_S
Discharge pressure (psig)
280
300
320
340
200
180
160
220
240
260
59
68
77
86
95
104
(15)
(20)
(25)
(30)
(35)
(40)
Outdoor ambient temp.
°
F (
°
C)
Indoor
temp.
°
F (
°
C)
Outdoor fan speed
Low
High
70 (21)
85 (30)
80 (27)
75 (24)
1800_X_S
Suction pressure (psig)
100
60
50
40
70
80
90
59
68
77
86
95
104
(15)
(20)
(25)
(30)
(35)
(40)
Outdoor ambient temp.
°
F (
°
C)
Indoor
temp.
°
F (
°
C)
Outdoor fan speed
Low
High
70 (21)
85 (30)
80 (27)
75 (24)
