4. COOLING CAPACITY
1
1
1
1
1
Indoor Unit: XS4232
Outdoor Unit: C4232, CL4232
• 208V / 1 phase / 60Hz
RATING CAPACITY :
40,500 BTU / h
AIR FLOW RATE :
880 CFM
EVAPORATOR
CONDENSER
ENT. TEMP.
°
F (
°
C)
AMBIENT TEMP.
°
F (
°
C)
WB
DB
75
85
95
105
115
(23.9)
(29.4)
(35.0)
(40.6)
(46.1)
TC
41,030
39,040
36,770
34,220
31,390
CI
2.97
3.24
3.53
3.95
4.37
72(22.2)
SHC
27,990
26,830
25,550
24,150
22,650
59
76(24.4)
SHC
30,830
29,680
28,400
27,000
25,500
(15.0)
80(26.7)
SHC
33,810
32,650
31,370
29,980
28,480
84(28.9)
SHC
36,660
35,500
34,220
32,820
31,320
88(31.1)
SHC
39,500
38,350
36,770
34,220
31,390
TC
42,570
40,660
38,640
36,330
33,820
CI
3
3.29
3.58
4.01
4.44
72(22.2)
SHC
24,210
23,190
22,140
20,970
19,730
63
76(24.4)
SHC
27,050
26,030
24,980
23,810
22,580
(17.2)
80(26.7)
SHC
30,030
29,010
27,960
26,790
25,560
84(28.9)
SHC
32,880
31,860
30,810
29,640
28,400
88(31.1)
SHC
35,720
34,710
33,650
32,480
31,250
TC
44,190
42,440
# 40,500
38,350
36,000
CI
3.02
3.31
3.62
4.05
4.48
72(22.2)
SHC
20,400
19,550
18,620
17,620
16,560
67
76(24.4)
SHC
23,250
22,390
21,470
20,470
19,400
(19.4)
80(26.7)
SHC
26,220
25,370
24,450
23,450
22,380
84(28.9)
SHC
29,070
28,220
27,290
26,290
25,230
88(31.1)
SHC
31,920
31,060
30,140
29,140
28,070
TC
46,530
44,910
43,170
41,270
39,160
CI
3.06
3.35
3.67
4.11
4.55
72(22.2)
SHC
16,690
15,970
15,210
14,400
13,510
71
76(24.4)
SHC
19,530
18,810
18,050
17,240
16,360
(21.7)
80(26.7)
SHC
22,510
21,790
21,030
20,220
19,340
84(28.9)
SHC
25,360
24,640
23,880
23,070
22,180
88(31.1)
SHC
28,200
27,480
26,720
25,910
25,030
TC
47,470
45,930
44,310
42,440
40,460
CI
3.11
3.4
3.73
4.17
4.61
75
76(24.4)
SHC
15,330
14,720
14,090
13,370
12,620
(23.9)
80(26.7)
SHC
18,310
17,700
17,060
16,340
15,600
84(28.9)
SHC
21,160
20,540
19,910
19,190
18,450
88(31.1)
SHC
24,000
23,390
22,760
22,040
21,290
TC
: Total Cooling Capacity (BTU / h)
SHC : Sensible Heat Capacity (BTU / h)
CI
: Compressor Input
(kW)
Rating conditions are
: Outdoor Ambient Temp. 95
°
F DB
: Indoor Unit Entering Air Temp. 80
°
F DB / 67
°
F WB
