5. PERFORMANCE CHARTS
(1) Operating Current
4 4 4 4 4 Indoor Unit: TS4232 Outdoor Unit: CL4232
Operating current characteristics versus outdoor ambient temperature and indoor temperature.
(Indoor relative humidity: 50%, Indoor fan speed: High)
230V
208V
1798_X_S
Oper
ating current (A)
21
22
23
17
16
15
18
19
20
23 32 41 50 59 68
(-5) (0) (5) (10) (15) (20)
77
(25)
86
(30)
95
(35)
104
(40)
Outdoor ambient temp.
°
F (
°
C)
Indoor
temp.
°
F (
°
C)
Outdoor fan speed (Upper / Lower)
STOP / Med Low / Low Med / Med High / High
70 (21)
85 (30)
80 (27)
75 (24)
1799_X_S
Oper
ating current (A)
23 32 41 50 59 68
(-5) (0) (5) (10) (15) (20)
77
(25)
86
(30)
95
(35)
104
(40)
Outdoor ambient temp.
°
F (
°
C)
Indoor
temp.
°
F (
°
C)
Outdoor fan speed (Upper / Lower)
STOP / Med Low / Low Med / Med High / High
70 (21)
85 (30)
80 (27)
75 (24)
21
22
23
17
16
15
18
19
20
