– 11 –
SM830078
(2)
Major Component Specifications
(A)
Indoor Unit
2. SPECIFICATIONS
MODEL No.
TS4232
Source
230 - 208 V / 1 phase / 60 Hz
Remote controller (Accessory)
RCS - 5PS4U
Controller P. C. B Ass'y
CR - TS2432
Control circuit fuse
250 V, 3 A
Switch Ass'y
SW - X363GS
Fan (Number … diameter)
in.
(mm)
Centrifugal (4 ... 5-29/32(150))
Fan motor
Model
KFG4X - 101C6P
Source
230 - 208 V / 1 phase / 60 Hz
No. of pole … r.p.m. (230 V, High)
rpm
1,015
Nominal output
W
100
Coil resistance
Ω
BRW - WHT
:
61.05
,
ORG - YEL
:
13.23
(Ambient temperature 68
°
F)
WHT - VLT
:
9.955 ,
YEL
- BLK
:
19.25
VLT
- ORG
:
9.576 ,
BLK
- PNK
:
10.81
Safety device
Operating temperature
Open
°
F
266
±
14.4
Close
°
F
174.2
±
27
Run capacitor
VAC,
µ
F
440 V , 4
µ
F
Heat exchanger
Coil
Aluminum plate fin / Copper tube
Rows … Fins per inch
3 … 14.9
Face area
ft.
2
(m
2
)
3.51 (0.326)
Auto louver motor
Model No.
MT8 - 3C
Auto louver motor … Rated
V, W, rpm
240 VAC , 3 W , 3 rpm
Coil resistance (Ambient temperature 77
°
F)
Ω
16,430
Ω
±
8 %
DATA SUBJECT TO CHANGE WITHOUT NOTICE
