5-3
STAR Command Specifications
Rev. 0.70
2. Header 2
Header 2 is the 1 byte length information transmitted from the second byte of the auto status.The table below shows
the composition of the Header 2.
Header 2 represents the auto status version (called automatic status version below) using bit 1 to bit 3 and bit 5.
For reference, the table below shows the relationship of actual version bytes and the Header 2.The auto status version
will be used as new information is added to the printer status bit positions that were empty, by adding new functions in
the future.
When the host does not control the auto status version, it is acceptable to ignore Header 2 received.
Bit Contents
Status By model
“0” “1”
BD100 SP2000 BD500 SP500 SP700
7 ASB status expansion
No
Expansion
Expansion - - - - -
6 Version Number - ○ ○ ○ ○ ○
5 Version Number ○ ○ ○ ○ ○
4 Fixed at “0” - - - - - -
3 Version Number ○ ○ ○ ○ ○
2 Version Number ○ ○ ○ ○ ○
1 Version Number ○ ○ ○ ○ ○
0 Fixed at “0” - - - - - -
Actual automatic status version and header 2 table
Version Number n Header 2 Contents
1 00000010B (02 Hex) Up to printer status 5 (7 th byte) loaded
2 00000100B (04 Hex)
3 00000110B (06 Hex) Up to printer status 7 (9 th byte) loaded
4 00001000B (08 Hex)
5 00001010B (0A Hex)
6 00001100B (0C Hex)
7 00001110B (0E Hex)
8 00100000B (20 Hex)
9 00100010B (22 Hex)
-
-
-
-
-
30 01101100B (6C Hex)
31 01101110B (6E Hex)
