3-47 STAR Command Specifications
Rev. 0.70
ESC FS p n m
[Name] Print logo
[Code]
ASCII ESC FS p n m
Hexadecimal 1B 1C 70 n m
Decimal 27 28 112 n m
[Defined Area]
1 ≤ n ≤ 255 (When printing normally)
0 ≤ m ≤ 3
48 ≤ m ≤ 51 (“0” ≤ m ≤ “3”)
[Initial Value] ---
[Function] Prints the logo of the number n registered using the logo registration command according to the print mode
m.
n: Logo Specification
n Function Remarks
1 to 255 Specified logo number
m: Print Mode
m Print Size Horizontal Direction Dot Density
(DPI) *1
Vertical Direction Dot Density
(DPI)
Remarks
0, 48 Normal Double density (169.3) Double density (144)
1, 49 Horizontal double size Standard density (84.7) Double density (144)
2, 50 Vertical double size Double density (169.3) Standard density (72)
3, 51 Double high/wide Standard density (84.7) Standard density (72)
*1: The actual value of the dot pitch in the horizontal direction is 0.30 mm for standard density and 0.15 mm
for double density .
• If the parameter is within the defined region, execute this command after printing the unprinted data in the
line buffer.
(Unprinted data is printed regardless of whether the specified logo was registered by n.)
Therefore, it is not possible to print with other data in the same line (characters, bit images, bar codes).
• For horizontal double density, logo data that is continuously ON in the horizontal direction, the printer
automatically thins out the data.
In such cases, right side data of the data that is continuously ON is forced OFF.
• Print modes, excluding upside-down printing (enhanced, double, underline, character size, black/white
inverted, and 90˚ right rotation) are unaffected.
• If the logo horizontal print size exceeds the print region, the portion exceeding the area is not printed.
• This command is affected by the following command settings.
• Left margin (ESC I n)
• Right margin (ESC Q n)
• Position alignment (ESC GS a n)
• Absolute position movement (ESC GS A n1 n2)
• Absolute position movement (ESC GS R n1 n2)
• Print region setting (ESC RS A n)
• Horizontal tab (HT)
• Upside-down printing (SI)
