3-78

STAR Command Specifications

Rev. 0.70

ESC RS m n

[Name]

Enable, disable black mark detection

[Code]

ASCII

ESC

RS

m

n

Hexadecimal

1B

1E

6D

n

Decimal

27

30

109

n

[Defined Area]

n = 0, 1, 2, 48, 49, 50

[Initial Value]

Memory SW

[Function]

Switchest to enable/disable black mark (BM) detection control

When switching the setting, operations are the same as when switching to enable/disable using the memory

switch. (However, that excludes the TOF operation that occurs when the power is turned ON.)

n

Black mark detection settings

0, 48

Invalid

1, 49

Valid

2, 50

Executes validate + TOP to the BM cutting position + paper full cut (SP542)
This command executes a BM TOF + paper full cut only when the current setting is
specified from invalid to valid using this command. (*)

(*) Precautions when specifying n = 2

Normally, when specifed from a state where BM is valid to become invalid, the TOF to the BM cutting position

+ paper full cut is not executed. However, if this command (n = 2) is specified when the BM TOF has not been

executed once, the same operation is executed after replacing paper.

For reference, see the functions and commands below that are affected when this setting is switched.

Affected Functions

Function

When BM is Valid (n = 1, 2, 49, 50)

When BM is Invalid (n = 0, 48)

Press FEED

Top of form to printing start position

Feed one line

BM Error

Supported

Invalid

Memory switch (for BM)

Supported

Invalid

EOT status (for BM)

Supported

Invalid

ASB status (for BM)

Supported

Invalid

Affected Commands

Class

Commands When BM is Valid (n = 1, 2, 49, 50)

When BM is Invalid (n = 0, 48)

BM Command

FF

Top of form to printing start position

Form feed

ESC d 2

TOF to cutting position + full cut

Paper fed to cutting position + full cut

ESC d 3

TOF to cutting position + partial cut

Paper fed to cutting position + partial cut

Page control

ESC C

Ignored

Set page length to n lines

ESC C 0

Ignored

Set page length to n inches

VT

Ignored

Feed paper to vertical tab position

ESC B

Ignored

Set vertical tab position

ESC N

Ignored

Set bottom margin to n lines

ESC O

Ignored

Cancel bottom margin

Note that at the point that this setting is switched, the current position is cleared to its default value in the

same way as turning the power ON.

Also, the auto-status BM sensor detection is also initialized to white.

This command is normally used with black mark detection set to “valid” by the memory switch, and it is

recommended to switch to “invalid” just once if necessary. Do not dynamically switch between valid and

invalid for each receipt.
