Rev. 1.3 69
C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D
8. Voltage Regulator (REG0)
C8051F34x devices include a voltage regulator (REG0). When enabled, the REG0 output appears on the
V
DD
pin and can be used to power external devices. REG0 can be enabled/disabled by software using bit
REGEN in register REG0CN. See Table 8.1 for REG0 electrical characteristics.
Note that the VBUS signal must be connected to the VBUS pin when using the device in a USB network.
The VBUS signal should only be connected to the REGIN pin when operating the device as a bus-powered
function. REG0 configuration options are shown in Figure 8.1–Figure 8.4.
8.1. Regulator Mode Selection
REG0 offers a low power mode intended for use when the device is in suspend mode. In this low power
mode, the REG0 output remains as specified; however the REG0 dynamic performance (response time) is
degraded. See Table 8.1 for normal and low power mode supply current specifications. The REG0 mode
selection is controlled via the REGMOD bit in register REG0CN.
8.2. VBUS Detection
When the USB Function Controller is used (see section Section “16. Universal Serial Bus Controller
(USB0)” on page 159 ), the VBUS signal should be connected to the VBUS pin. The VBSTAT bit (register
REG0CN) indicates the current logic level of the VBUS signal. If enabled, a VBUS interrupt will be gener-
ated when the VBUS signal matches the polarity selected by the VBPOL bit in register REG0CN. The
VBUS interrupt is level-sensitive, and has no associated interrupt pending flag. The VBUS interrupt will be
active as long as the VBUS signal matches the polarity selected by VBPOL. See Table 8.1 for VBUS input
parameters.
Important Note: When USB is selected as a reset source, a system reset will be generated when the
VBUS signal matches the polarity selected by the VBPOL bit. See
Section “11. Reset Sources” on
page 100 for details on selecting USB as a reset source
Table 8.1. Voltage Regulator Electrical Specifications
–40 to +85 °C unless otherwise specified.
Parameter Conditions Min Typ Max Units
Input Voltage Range
1 2.7 5.25 V
Output Voltage (V
DD
)
2 Output Current = 1 to 100 mA 3.0 3.3 3.6 V
Output Current
2 100 mA
VBUS Detection Input Low Voltage 1.0 V
VBUS Detection Input High Voltage 3.0 V
Bias Current
Normal Mode (REGMOD = ‘0’)
Low Power Mode (REGMOD = ‘1’) 65
35 111
61
µA
Dropout Voltage (V
DO
)
3
1 mV/mA
Notes:
1. Input range specified for regulation. When an external regulator is used, should be tied to V
DD
.
2. Output current is total regulator output, including any current required by the C8051F34x.
3. The minimum input voltage is 2.70 V or VDD + V
DO
(max load), whichever is greater.
