SSG 20 Hardware Installation and Configuration Guide
80
Figure 40: Eth0/1 Interface Window
Table 25: Fields in Eth0/1 Interface Window
12. Bgroup0 Interface (Trust Zone) Window
The bgroup0 interface can have a static or a dynamic IP address assigned via DHCP.
The default interface IP address is 192.168.1.1 with a netmask of 255.255.255.0 or
24.
Figure 41: Bgroup0 Interface Window
Field
Description
Dynamic IP via DHCP
Enables the device to receive an IP address for the DMZ interface
from a service provider.
Static IP
Assigns a unique and fixed IP address to the DMZ interface. Enter
the DMZ interface IP and netmask.
