Front Panel

„

15

Table 4: Mini PIM LED States on the SSG 20

Type

Name

Color

State

Description

ADSL 2/2+

(Annex A
and B)

SYNC

Green

On steadily Indicates that the ADSL interface is trained

Blinking

Indicates training is in progress

Off

Indicates that the interface is idle

TX/RX

Green

Blinking

Indicates that traffic is passing through

Off

Indicates that no traffic is passing through

ISDN (BRI)

CH B1

Green

On steadily Indicates that B-Channel 1 is active

Off

Indicates that B-Channel 1 is not active

CH B2

Green

On steadily Indicates that B-Channel 2 is active

Off

Indicates that B-Channel 2 is not active

T1/E1

ALARM

Yellow

On steadily Indicates that there is a local or remote

alarm; device has detected a failure

Off

Indicates that there are no alarms or failures

LOOP BACK

Yellow

On steadily Indicates that a loopback or line state is

detected

Off

Indicates that the loopback is not active

CD

Green

On steadily Indicates a carrier was detected and the

internal DSU/CSU in the mini PIM is
communicating with another DSU/CSU

Off

Indicates that carrier detect is not active

V.92

CD

Green

On steadily Indicates that the link is active

Off

Indicates that the serial interface is not in
service

TX/RX

Green

Blinking

Indicates that traffic is passing through

Off

Indicates that no traffic is passing through

CAUTION:

Mini PIMs are not hot-swappable. You must install them in the front

panel slots before powering on the device.
