„ 77
Figure 37: ISDN Connection Tab Window
Table 22: Fields in ISDN Connection Tab Window
Field Description
PPP Profile Name Sets a PPP profile name to the ISDN interface.
Authentication Sets the PPP authentication type:
„ Any
„ CHAP: Challenge Handshake Authentication Protocol
„ PAP: Password Authentication Protocol
„ None
Local User Sets the local user.
Password Sets the password for the local user.
Static IP checkbox Enables a static IP address for the interface.
Interface IP Sets the interface IP address.
Interface Name
(Dialer only) Sets the dialer interface name. Default is dialer.1.
Encapsulation Type Sets the encapsulation type on the dialer and dialer using BRI
interface. Default is PPP.
Primary Number Sets the primary number for dialer and dialer using BRI interfaces.
Alternative Number Sets the alternative (secondary) number to be used when the primary
number cannot be used for connectivity.
