SSG 20 Hardware Installation and Configuration Guide
12 „ Front Panel
PIM 2 Green On steadily Indicates that the mini PIM is functioning.
Blinking Indicates that the mini PIM is passing traffic.
Off Indicates that the mini PIM is not
operational.
WLAN (On WLAN device only)
802.11a Green On steadily Indicates that a wireless connection is
established but there is no link activity.
Blinking slowly Indicates that a wireless connection is
established. The baud rate is proportional to
the link activity.
Off Indicates that there is no wireless connection
established.
b/g Green On steadily Indicates that a wireless connection is
established but there is no link activity.
Blinking slowly Indicates that a wireless connection is
established. The baud rate is proportional to
the link activity.
Off Indicates that there is no wireless connection
established.
Name Color Status Description
