SSG 20 Hardware Installation and Configuration Guide
38 „ Basic Wireless Configuration
Once you have set an SSID to the wireless0/0 interface, you can access the device
using the default wireless0/0 interface IP address in the steps described in
“Accessing a Device” on page 28. Figure 15 shows the default configuration for the
SSG 20-WLAN device.
Figure 15: Default SSG 20-WLAN Configuration
By default, the wireless0/0 interface is configured with the IP address
192.168.2.1/24. All wireless clients that need to connect to the Trust zone must
have an IP address in the wireless subnetwork. You can also configure the device to
use DHCP to automatically assign IP addresses in the 192.168.2.1/24 subnetwork to
your devices.
By default, the wireless0/1 – wireless0/3 interfaces are defined as Null and do not
have IP addresses assigned to them. If you want to use any of the other wireless
interfaces, you must configure an IP address for it, assign an SSID to it, and bind it
to a security zone. Table 7 displays the wireless authentication and encryption
methods.
NOTE: If you are operating the SSG 20-WLAN device in a country other than the United
States, Japan, Canada, China, Taiwan, Korea, Israel, or Singapore, then you must
use the set wlan country-code CLI command or set it on the Wireless > General
Settings WebUI page before a WLAN connection can be established. This
command sets the selectable channel range and the transmit power level.
If your regional code is ETSI, you must set the correct country code that meets
your local radio spectrum regulations.
AUX 0 / 0 10 /100 AUX 0 /0 10/100 0 /0 10/100 0/ 0 10 /100 0/ 0 10 /100
LI NK
STATUS
POWER PI M 2 PI M 1 b/g 802.11a
WLAN
SSG 20
1 2
Untrust
Zone
Trust Zone
wireless0/0
Console
DMZ
