SSG 20 Hardware Installation and Configuration Guide
70
Figure 30: T1 Frame Relay Tab Window
Table 15: Fields in T1 Frame Relay Tab Window
Field
Description
No-Keepalive checkbox
Enables no-keepalives.
Type
Sets the frame relay LMI type:
ANSI: American National Standards Institute supports data rates
up to 8Mbps downstream and 1Mbps upstream.
ITU: International Telecommunications Union supports data rates
of 6.144 Mbps downstream and 640 kbps upstream.
Interface Name
Sets the subinterface name.
Inverse ARP
Enables inverse Address Resolution Protocol for the subinterface.
Frame Relay DLCI
Assigns a data link connection identifier (DLCI) to the subinterface.
Interface IP
Sets the IP address for the subinterface.
Netmask
Sets the netmask for the subinterface.
Gateway
Sets the gateway address for the subinterface.
