„ 73
Table 18: Fields in Cisco HDLC Option with Cisco HDLC Tab Window
7. E1 Interface Windows
If you have the E1 mini-PIM installed in your device and you selected the Frame
Relay option, the following windows are displayed:
„ E1 Physical Layer Tab Window
„ E1 Frame Relay Tab Window
Figure 34: E1 Physical Layer Tab Window
Field Description
Interface IP Sets the IP address for the T1 Cisco HDLC interface
Netmask Sets the netmask for the T1 Cisco HDLC interface
Gateway Sets the gateway address for the T1 Cisco HDLC interface
NOTE: If you have two E1 mini PIMs installed on your device and you select the Multi-link
option, you will see two Physical Layer tabs.
