Chapter 23 Configuring QoS
Configuring Standard QoS
Beginning in privileged EXEC mode, follow these steps to create a policy map:
Command
Purpose
Step 1
configure terminal
Enter global configuration mode.
Step 2
access-list access-list-number permit
{source source-wildcard | host source |
any}
or
access-list access-list-number
{permit | remark} protocol
{source source-wildcard | host
source |
any
} [operator port] {destination
destination-wildcard | host
destination |
any}
[operator port] [dscp dscp-value]
[time-range time-range-name]
or
mac access-list extended name
permit {any | host source MAC address}
{any | host destination MAC address}
[aarp | amber | appletalk |dec-spanning |
decnet-iv | diagnostic | dsm | etype-6000 |
etype-8042 | lat | lavc-sca | mop-console |
mop-dump | msdos | mumps | netbios |
vines-echo |vines-ip | xns-idp]
Create an IP standard or extended ACL for IP traffic or a Layer 2 MAC
ACL for non-IP traffic, repeating the command as many times as
necessary.
For more information, see the
“Classifying Traffic by Using ACLs”
Note
Deny statements are not supported for QoS ACLs. See the
“Classification Based on QoS ACLs” section on page 23-5
for
more details.
For more information on the mac access-list extended name
command, see the
“Creating Named MAC Extended ACLs” section on
Step 3
policy-map policy-map-name
Create a policy map by entering the policy map name, and enter
policy-map configuration mode.
By default, no policy maps are defined.
The default behavior of a policy map is to set the DSCP to 0 if the
packet is an IP packet and to set the CoS to 0 if the packet is tagged. No
policing is performed.
Step 4
class class-map-name [access-group name
acl-index-or-name]
Define a traffic classification, and enter policy-map class configuration
mode.
By default, no policy map class maps are defined.
If a traffic class has already been defined by using the class-map global
configuration command, specify its name for class-map-name in this
command.
For access-group name acl-index-or-name, specify the number or name
of the ACL created in Step 2.
Note
In a policy map, the class named class-default is not supported.
The switch does not filter traffic based on the policy map
defined by the class class-default policy-map configuration
command.
