Chapter 7 Configuring Interface Characteristics
Configuring Ethernet Interfaces
This example shows how to delete the interface-range macro enet_list and to verify that it has been
deleted.
Switch# configure terminal
Switch(config)# no define interface-range enet_list
Switch# show run | include define
Configuring Ethernet Interfaces
The switch supports these interface types:
• Physical ports—Switch ports, including access and trunk ports
• Port channels—EtherChannel of interfaces
• VLANs
These sections describe the default interface configuration and the optional features that you can
configure on most physical interfaces:
• Default Ethernet Interface Configuration, page 7-9
• Configuring Interface Speed and Duplex Mode, page 7-10
• Adding a Description for an Interface, page 7-12
Default Ethernet Interface Configuration
Table 7-1 shows the Ethernet interface default configuration. For more details on the VLAN parameters
listed in the table, see Chapter 12, “Configuring VLANs.” For details on controlling traffic to the port,
see Chapter 15, “Configuring Port-Based Traffic Control.”
Table 7-1 Default Ethernet Interface Configuration
Feature Default Setting
Operating mode Layer 2.
Allowed VLAN range VLAN ID range is 2 to 4094 on the internal 1000 Mbps ports
(ports 1 to 14).
VLAN ID range is 1 on the internal 100 Mbps management
module ports (ports 15 and 16).
VLAN ID range is 2 on the external ports (ports 17 to 20).
Default VLAN (for access ports) VLAN 2 on the internal 1000 Mbps ports (ports 1 to 14)
Native VLAN 1 on the internal 100 Mbps management
module ports (ports 15 and 16)
VLAN 1 on the external ports (ports 17 to 20).
Native VLAN (for IEEE 802.1Q
trunks) VLAN 2.
VLAN trunking Switchport mode dynamic desirable (supports DTP).
Port enable state All ports are enabled. See the installation guide for
information about changing this value.
