22-7
Cisco Systems Intelligent Gigabit Ethernet Switch Modules for the IBM BladeCenter, Software Configuration Guide
24R9746
Chapter 22 Configuring Network Security with ACLs
Configuring ACLs
Creating Standard and Extended IP ACLs
This section describes how to create switch IP ACLs. The switch tests packets against the conditions in
an access list one by one. The first match determines whether the switch accepts or rejects the packet.
Because the switch stops testing conditions after the first match, the order of the conditions is critical.
If no conditions match, the switch denies the packet.
Follow these steps to use ACLs:
Step 1
Create an ACL by specifying an access list number or name and access conditions.
Step 2
Apply the ACL to interfaces or terminal lines.
The software supports these kinds of IP access lists:
•
Standard IP access lists use source addresses for matching operations.
•
Extended IP access lists use source and destination addresses for matching operations and optional
protocol-type information for finer granularity of control.
Note
MAC extended access list use source and destination MAC addresses and optional protocol type
information for matching operations. For more information, see the
The next sections describe access lists and the steps for using them.
ACL Numbers
The number you use to denote your ACL shows the type of access list that you are creating.
lists the access list number and corresponding type and shows whether or not they are supported by the
switch. The switch supports IP standard and IP extended access lists, numbers 1 to 199 and 1300 to 2699.
Table 22-2
Access List Numbers
ACL Number
Type
Supported
1–99
IP standard access list
Yes
100–199
IP extended access list
Yes
200–299
Protocol type-code access list
No
300–399
DECnet access list
No
400–499
XNS standard access list
No
500–599
XNS extended access list
No
600–699
AppleTalk access list
No
700–799
48-bit MAC address access list
No
800–899
IPX standard access list
No
900–999
IPX extended access list
No
1000–1099
IPX SAP access list
No
1100–1199
Extended 48-bit MAC address access list
No
