Motherboard Layout and Routing Guidelines
2-28 Intel
®
440GX AGPset Design Guide
Table 2-19. Motherboard Model: SRAS_B#, 4 DIMMs
Table 2-20. Motherboard Model: SCAS_A#, 4 DIMMs
Table 2-21. Motherboard Model: SCAS_B#, 4 DIMMs
82443GX
1.0” - 3.0” 0.4” - 0.6”
D
IMM
Mo
d
u
le
3
D
IMM
Mo
d
u
le
4
82443GX
1.0” - 3.0” 0.4” - 0.6”
DI
MM M
odu
le
1
DI
MM M
odu
le
2
82443GX
1.0” - 3.0” 0.4” - 0.6”
DIMM
Mod
ul
e 3
DIMM
Mod
ul
e 4
