Page 36
Connecting the Power Cord
QMS 1725E Print System Getting Started
2-12
3
Insert the tab on the end of the media guide arm into the slot.
Lower the arm onto the top output bin.
Connecting the Power Cord
1
Plug one end of the power cord into the connector just below
the main power switch on the back of the printer.
2
Plug the other end of the power cord into a standard electri-
cal wall outlet (grounded AC outlet).
Turning on the Printer
1
Push in the | on the main power switch, located on the back
of the printer above the power cord.
Media guide arm
Tab
