Removing paper from the transfer charge roller – IBM Print System QMS 1725E User Manual
Page 30
Removing Packing Materials
QMS 1725E Print System Getting Started
2-6
1
Pull the top cover release button (located on top of the
printer opposite the control panel) forward to open the
printer top section.
2
Locate the two spacers with orange tags.
One is on each side of the fuser assembly.
3
Grasp the spacers and gently pull them out from under the
fuser assembly.
4
Check inside the printer to make sure there are no other
packing materials.
Removing Paper from the Transfer Charge
Roller
O Caution: Make sure you leave this sheet of paper in place until the spacers
have been removed. Permanent damage to the roller could result if any
contaminants get on the roller.
