Extensible Firmware Interface Specification
E-84 12/01/02 Version 1.10
// Array of packet fragment descriptors. The first byte of the
// media header is the first byte of the first fragment.
struct {
// Address of this packet fragment.
PXE_UINT64 FragAddr;
// Length of this packet fragment.
PXE_UINT32 FragLen;
// Reserved, must be set to zero.
PXE_UINT32 reserved;
} FragDesc[n];
} PXE_CPB_FILL_HEADER_FRAGMENTED;
#pragma pack()
E.4.17.2 Waiting for the Command to Execute
Monitor the upper two bits (14 & 15) in the CDB.StatFlags field. Until these bits change to
report PXE_STATFLAGS_COMMAND_COMPLETE or PXE_STATFLAGS_COMMAND_FAILED ,
the command has not been executed by the UNDI.
StatFlags Reason
COMMAND_COMPLETE Command completed successfully. Frame is ready to transmit.
COMMAND_FAILED Command failed. StatCode field contains error code.
COMMAND_QUEUED Command has been queued.
INITIALIZE Command has been not executed or queued.
E.4.17.3 Checking Command Execution Results
After command execution completes, either successfully or not, the CDB.StatCode field
contains the result of the command execution.
StatCode Reason
SUCCESS Command completed successfully. Frame is ready to transmit.
INVALID_CDB One of the CDB fields was not set correctly.
INVALID_CPB One of the CPB fields was not set correctly.
BUSY UNDI is already processing commands. Try again later.
QUEUE_FULL Command queue is full. Try again later.
NOT_STARTED The UNDI is not started.
NOT_INITIALIZED The UNDI is not initialized.
