Intel Extensible Firmware Interface User Manual
Page 727
Protocols
— Debugger Support
Version 1.10
12/01/02
16-13
EFI_DEBUG_SUPPORT_PROTOCOL.InvalidateInstructionCache()
Summary
Invalidates processor instruction cache for a memory range. Subsequent execution in this range
causes a fresh memory fetch to retrieve code to be executed.
Prototype
typedef
EFI_STATUS
(EFIAPI *EFI_INVALIDATE_INSTRUCTION_CACHE) (
IN EFI_DEBUG_SUPPORT_PROTOCOL
*This,
IN UINTN
ProcessorIndex,
IN VOID
*Start,
IN UINT64
Length
);
Parameters
This
A pointer to the
instance.
Type
EFI_DEBUG_SUPPORT_PROTOCOL
is defined in Section 16.2.
ProcessorIndex
Specifies which processor’s instruction cache is to be invalidated.
Start
Specifies the physical base of the memory range to be invalidated.
Length
Specifies the minimum number of bytes in the processor’s instruction
cache to invalidate.
Description
Typical operation of a debugger may require modifying the code image that is under debug. This
can occur for many reasons, but is typically done to insert/remove software break instructions.
Some processor architectures do not have coherent instruction and data caches so modifications to
the code image require that the instruction cache be explicitly invalidated in that memory region.
The
InvalidateInstructionCache()
function abstracts this operation from the debug
agent and provides a general purpose capability to invalidate the processor’s instruction cache.
It is the responsibility of the caller to insure all parameters are correct. There is no provision for
parameter checking by
. The implementation behavior
when an invalid parameter is passed is not defined by this specification.
Status Codes Returned
EFI_SUCCESS
The function completed successfully.
