Extensible Firmware Interface Specification
19-24 12/01/02 Version 1.10
DIV
SYNTAX:
DIV[32|64] {@}R
1
, {@}R
2
{Index16|Immed16}
DESCRIPTION:
Performs a divide operation on two signed operands and stores the result to Operand 1. The
operation can be performed on either 32-bit (DIV32) or 64-bit (DIV64) operands.
OPERATION:
Operand 1 <= Operand 1 / Operand 2
Table 19-16 DIV Instruction Encoding
BYTE DESCRIPTION
Bit Description
7 0 = Immediate/index absent
1 = Immediate/index present
6 0 = 32-bit operation
1 = 64-bit operation
0
0..5 Opcode = 0x10
Bit Description
7 0 = Operand 2 direct
1 = Operand 2 indirect
4..6 Operand 2
3 0 = Operand 1 direct
1 = Operand 1 indirect
1
0..2 Operand 1
2..3 Optional 16-bit immediate data/index
BEHAVIORS AND RESTRICTIONS:
• If Operand 2 is indirect, then the immediate data is interpreted as an index, and the Operand 2
value is fetched from memory as a signed value at address [R
2
+ Index16].
• If Operand 2 is direct, then the immediate data is considered a signed value and is added to the
register contents such that Operand 2 = R
2
+ Immed16
• If the instruction is DIV32 form, and Operand 1 is direct, then the upper 32 bits of the result are
set to 0 before storing to the Operand 1 register.
• A divide-by-0 exception occurs if Operand 2 = 0.
