Another example is a USB Controller (interface number 0) that is connected to port 3 of a USB
Hub Controller (interface number 0), and this USB Hub Controller is connected to the port 1 of the
root hub. The shorthand notation for this device path is:
ACPI(PNP0A03,0)/PCI(1F|2)/USB(1,0)/USB(3,0) .
Table 14-5 shows the device path for this USB Controller.
Table 14-5. Another USB Device Path Example
Byte
Offset Byte
Length
Data
Description
0x00 0x01 0x02 Generic Device Path Header – Type ACPI Device Path
0x01 0x01 0x01 Sub type – ACPI Device Path
0x02 0x02 0x0C Length – 0x0C bytes
0x04 0x04 0x41D0,
0x0A03
_HID PNP0A03 – 0x41D0 represents a compressed string ‘PNP’ and is in
the low order bytes.
0x08 0x04 0x0000 _UID
0x0C 0x01 0x01 Generic Device Path Header – Type Hardware Device Path
0x0D 0x01 0x01 Sub type – PCI
0x0E 0x02 0x06 Length – 0x06 bytes
0x10 0x01 0x1F PCI Function
0x11 0x01 0x02 PCI Device
0x12 0x01 0x03 Generic Device Path Header – Type Message Device Path
0x13 0x01 0x05 Sub type – USB
0x14 0x02 0x06 Length – 0x06 bytes
0x16 0x01 0x01 Parent Hub Port Number.
0x17 0x01 0x00 Controller Interface Number.
0x18 0x01 0x03 Generic Device Path Header – Type Message Device Path
0x19 0x01 0x05 Sub type – USB
0x1A 0x02 0x06 Length – 0x06 bytes
0x1C 0x01 0x03 Parent Hub Port Number.
0x1D 0x01 0x00 Controller Interface Number.
0x1E 0x01 0xFF Generic Device Path Header – Type End of Hardware Device Path
0x1F 0x01 0xFF Sub type – End of Entire Device Path
0x20 0x02 0x04 Length – 0x04 bytes
