EFI Byte Code Virtual Machine
Version 1.10 12/01/02 19-49
NOT
SYNTAX:
NOT[32|64] {@}R
1
, {@}R
2
{Index16|Immed16}
DESCRIPTION:
Performs a logical NOT operation on Operand 2, an unsigned 32-bit (NOT32) or 64-bit (NOT64)
value, and stores the result back to Operand 1.
OPERATION
Operand 1 <= NOT Operand 2
Table 19-35. NOT Instruction Encoding
BYTE DESCRIPTION
Bit Description
7 0 = Operand 2 immediate/index absent
1 = Operand 2 immediate/index present
6 0 = 32-bit operation
1 = 64-bit operation
0
0..5 Opcode = 0x0A
Bit Description
7 0 = Operand 2 direct
1 = Operand 2 indirect
4..6 Operand 2
3 0 = Operand 1 direct
1 = Operand 1 indirect
1
0..2 Operand 1
2..3 Optional 16-bit immediate data/index
BEHAVIORS AND RESTRICTIONS:
• If Operand 2 is indirect, then the immediate data is interpreted as an index, and the Operand 2
value is fetched from memory as an unsigned value at address [R
2
+ Index16].
• If Operand 2 is direct, then the immediate data is considered a signed immediate value and is
added to the Operand 2 register contents such that Operand 2 = R
2
+ Immed16.
• If the instruction is NOT32 and Operand 1 is a register, then the result is stored in the
Operand 1 register with the upper 32 bits cleared.
