450 Building a Network Access Control Solution with IBM Tivoli and Cisco Systems
collectors, at which time any state changes affected by the remediation process
will be discovered. The next time the network polls for StatusChange, it will
receive a
true response and will request the new posture data to evaluate
against the existing policy.
Details about this process can be found in the Security Compliance Manager
Client’s client.log file and several log files on the Web Gateway, including the
HTTP Server component’s access.log and the application-specific logs on the
WebSphere Application Server.
Security Compliance Manager server and client
Figure A-5 illustrates Tivoli Security Compliance Manager client/server
communication and the interaction between the server and client and associated
TCP port numbers.
Figure A-5 Communication port usage in Security Compliance Manager server and client
Figure A-5 shows the default port usage for Tivoli Security Compliance Manager.
The direction of the arrows in the diagram indicate the initiator of the
communication. For example, communication from the server to a push client is
initiated by the server on port 1950. Similarly, communication from a push client
to the server is initiated by the client on port 1951.
Tivoli Security Compliance Manager Server
Jlog
(local only)
TCP 1952
Push Client
TCP 1951
Java RMI to
Administration Utilities
TCP 1955
SCM Push Client
Jlog
(local only)
TCP 1953
Server to Client
TCP 1950
Administration console
and commands
Temporary connections
TCP - Transmission Control Protocol
