102 Building a Network Access Control Solution with IBM Tivoli and Cisco Systems
integrated solution include the Security Compliance Manager client/server
componentry and the Tivoli Configuration Manager remediation client/server
code.
In this section we see how these components map to the implementation
architecture.
Figure 5-3 Component subsystems - total solution
5.3.1 Logical components
For the purposes and scope of this book, we operate under the premise that
ABBC has the software distribution server subsystem based on the Tivoli
Configuration Manager installed and configured. For detailed information about
basic implementation of IBM Tivoli Configuration Manager refer to the product
documentation IBM Tivoli Configuration Manager Version 4.2.3 Planning and
Installation Guide, GC23-4702-03. Here we focus on extending the infrastructure
Network Admission
Control Subsystem
Cisco
Trust Agent
Cisco
Network
Access
Device
Cisco
Secure
Access
Control
Server
Compliance
Subsystem
IBM
Compliance
Client
IBM
Security
Compliance
Server
Remediation
Subsystem
IBM
Remediation
Client
IBM
Remediation
Server
