56K V.92 Data, Fax, and Voice Chipset
Programmer’s Guide Intel Confidential 9
I4 Reserved
I5
Reserved for modem chip hardware configu-
ration
I6 Country code
I7 Version of board manufacturer firmware
I8 Modem firmware features
I10
Modem board configuration — bits set by
board manufacturer
I11
Modem board configuration — bits set by
board manufacturer
I12 Reserved
I13 Reserved
I14 SAFE device
I20 Intel silicon version
I21 Intel firmware version
I22 Intel manufacturer name
I23 Intel product model
* Ln Speaker volume control 1 0–3 yes
L0 Low speaker volume
L1 Low speaker volume
L2 Medium speaker volume
L3 High speaker volume
* Mn Speaker control 1 0–3 yes
M0 Speaker always off
M1 Speaker on until carrier present
M2 Speaker always on
M3
Speaker off during dialing; speaker on until
carrier present
* Nn Select data rate handshake 1 0, 1 yes
N0 Handshake only at DTE-to-modem data rate
N1
Begins handshake at DTE-to-modem data
rate and falls to highest compatible rate
On Go online 0 0, 1 no
O0 Returns modem to Data mode
O1
Retrains equalizer and then returns to Data
mode
* P Select pulse dialing none – yes
* Qn Result code display control 0 0, 1 yes
Q0 Enables result codes
Table 2-1. Data Mode Command Summary (Continued)
Note Command Function Default Range
Reported by
&Vn
