56K V.92 Data, Fax, and Voice Chipset
116 Intel Confidential Programmer’s Guide
$TTnn 00
Tone Test Command, Continued:
Analog Loopback (ALB) Test:
n = 15 V.22 ALB, originate
n = 16 V.22 bis ALB, originate
n = 17 V.22 ALB, answer
n = 18 V.22 bis ALB, answer
n = 20 V.32 ALB, 9600, originate
n = 21 V.32 bis ALB, answer
n = 60 V.34 ALB, 2400bps
n = 61 V.34 ALB, 4800bps
n = 62 V.34 ALB, 7200bps
n = 63 V.34 ALB, 9600bps
n = 64 V.34 ALB, 12000bps
n = 65 V.34 ALB, 14400bps
n = 66 V.34 ALB, 16800bps
n = 67 V.34 ALB, 19200bps
n = 68 V.34 ALB, 21600bps
n = 69 V.34 ALB, 24000bps
n = 6a V.34 ALB, 26400bps
n = 6b V.34 ALB, 28800bps
n = 6c V.34 ALB, 31200bps
n = 6d V.34 ALB, 33600bps
FAX Test:
n = 40 FAX configure V.27, 300bps
n = 41 FAX configure V.27, 2400bps
n = 42 FAX configure V.27, 4800bps
n = 43 FAX configure V.29, 7200bps
n = 44 FAX configure V.29, 9600bps
n = 45 FAX configure V.17, 7200bps long train
n = 46 FAX configure V.17, 7200bps short train
n = 47 FAX configure V.17, 9600bps long train
n = 48 FAX configure V.17, 9600bps short train
n = 49 FAX configure V.17, 12000bps long train
n = 4a FAX configure V.17, 12000bps short train
n = 4b FAX configure V.17, 14400bps long train
n = 4c FAX configure V.17, 14400bps short train
Table 9-1. Manufacturing-Only Command Descriptions (Continued)
