56K V.92 Data, Fax, and Voice Chipset
58 Intel Confidential Programmer’s Guide
+MS=m
(cont.) see “m”
Modulation Selection: (cont.)
Range: = 0, 300, 1200, 2400, 4800, 7200, 9600, 12,000, 14,400, 16,800,
19,200, 21,600, 24,000, 26,400, 28,800, 31,200, 33,333, 33,600, 37,333, 41,333,
42,666, 44,000, 45,333, 46,666, 48,800, 49,333, 50,666, 52,000, 53,333, 54,666
a
,
and 56,000 a bps.
Default: = 0
= 0 Maximum allowed data rate:
- If the maximum modulation data rate is less than or
equal to the DTE data rate, then the highest data rate is
the highest modulation data rate.
- If the maximum modulation data rate is greater than
the DTE data rate, then the highest data rate is the
modulation data rate equal to or just below the DTE data
rate.
≠ 0 Highest permitted data rate
Table 3-4. Data Mode Command Descriptions (Continued)
Examples (DTE data rate = 115,200 bps) Speed Range
+MS = V32, 1, 0, 0 300–9600
+MS = V32, 0, 0, 0 4800–9600
+MS = V32B, 1, 9600, 14400 9600–14400
+MS = V34, 1, 0, 0 2400–28800
+MS = V34, 1, 2400, 28800 2400–28800
+MS = V34, 1, 9600, 28800 9600–28800
+MS = V34, 1, 28800, 28800 28800 only
+MS = V34, 0, 19200, 26400 19200–26400
+MS = V90, 1, 0, 50666 4800–50666
Examples (DTE data rate = 2400 bps) Speed Range
+MS = V32, 0, 0, 0 NO CARRIER
+MS = V32B, 1, 9600, 14400 9600–14400
+MS = V34, 1, 0, 0 2400–2400
+MS = V34, 1, 2400, 28800 2400–28800
+MS = V34, 1, 9600, 28800 9600–28800
+MS = V34, 1, 28800, 28800 28800 only
+MS = V34, 0, 0, 0 2400 only
+MS = V34, 0, 19200, 26400 9200–26400
+MS = V90, 1, 0, 50666 4800–50666
