Intel MD566X - Manual (Page 21)

56K V.92 Data, Fax, and Voice Chipset
Programmer’s Guide Intel Confidential 21
Note: The manufacturing-only S-registers S91 and S92 are listed in the Manufacturing-Only Commands
in
Table 2-13 on page 23 .
* Value saved in NVRAM.
* S22 Bit-mapped options 118 – – no
* S23 Bit-mapped options none – – no
* S25 Detect DTR change 5 0–255 0.01 second yes
* S27 Bit-mapped options 64 – – no
* S30 Disconnect inactivity timer 0 0–255 minute yes
* S31 Bit-mapped options 49 – – no
* S33 Sleep mode timer 10 0–90 second yes
* S37 Maximum line speed attempted 0 0–35 – yes
Table 2-9. S-Register Summary (Continued)
Note Register Function Default Range Units
Reported
by &Vn
Table 2-10. V.90/V.92 Mode DCE-to-ISP Response Codes
Verbose Code Numeric Code
CONNECT 33333 33
CONNECT 37333 34
CONNECT 41333 35
CONNECT 42667 36
CONNECT 44000 37
CONNECT 45333 38
CONNECT 46667 39
CONNECT 48000 42
CONNECT 49333 43
CONNECT 50667 53
CONNECT 52000 54
CONNECT 53333 55
CONNECT 54666 56
CONNECT 56000 57
CONNECT (DTE protocol) / data
compression / TX:(DCE transmit data
rate) / RX:(DCE receive data rate)
See Note following
Table 2-12 on page 23
