Setting Up WAN Properties
42
Interphase Corporation
N
OTE
If the Cards list is empty, the board might not be properly
installed. See
Problems and Solutions on page 166
for
information to correct the problem.
When configuring WAN port properties, if you are not sure
which options to select, use the default values. You can change
the settings later. For detailed information about setting up
WAN properties, press the F1 key to view field-level help, or
see
Setting up Firmware and Hardware on page 145
To set up port properties, do the following:
1. In the Cards list of the WAN Adapters Setup dialog box,
select the serial port and click Properties.
The SR Port Properties dialog box appears.
Figure 4-7. SR Port Properties Dialog Box
2. In the Interface field, select the serial line interface type
to be used with the adapter.
3. In the Modem signals field, select the method for
handling modem signals. (In most cases, the default
option, External modem, is appropriate.)
