Setting Up Channels for Logical Adapters
80 Interphase Corporation
Setting Up WAN Properties
The following illustration shows the WAN section of the
Channel properties dialog box.
Figure 5-11. WAN Channel Properties
To set up WAN properties for the channel, do the following:
1. Complete information in the fields in the WAN section
of the Channel properties dialog box as follows:
a. Check the PPP, X.25, or FR field to select the WAN
protocol to transport the selected LAN protocol(s).
b. If the X.25 protocol is selected, in the X.25 Address
field, enter the remote equipment address to use for
the X.25 protocol.
2. To set up properties for the selected WAN protocol,
click the Properties button in the WAN section.
The PPP Properties, X.25 Properties, or Frame Relay
dialog box appears, depending on the WAN protocol.
The topics that follow provide instructions for setting up WAN
protocol properties for a channel.
• To set up PPP properties, continue to the next topic,
PPP WAN Properties .
• To set up X.25 properties, skip to X.25 WAN Properties
on page 83 .
• To set up Frame Relay properties, skip to Frame Relay
WAN Properties on page 85 .
