Chapter 5: Setting Up the NDIS Driver
iSPAN Serial WAN Adapter Users Guide
89
b. On the X.25 protocol properties dialog box,
configure the X.25 network properties to use with
this channel. For instructions, see
Network Properties on page 150
.
All X.25 network configurations created in this
dialog box are available for use by all of the
adapter’s NDIS channels and SNA link services.
c. Click OK to save the X.25 protocol properties and
return to the Channel properties dialog box.
N
OTE
Because changing the X.25 network configuration
changes the adapter firmware, use the WAN Adapters
Setup utility to reload the firmware after making this
change, as described in
.
Frame Relay Port Properties
The following illustration shows the Port section of the
Channel properties dialog box when the Frame Relay (FR)
WAN protocol is selected.
Figure 5-18. Frame Relay Channel Port Properties
To set up port properties for a channel using the Frame Relay
protocol, do the following:
