Chapter 5: Setting Up the NDIS Driver
iSPAN Serial WAN Adapter Users Guide
91
Viewing Channel Status
To view channel status information, do the following:
1. If needed, start the NDIS driver Setup utility, as
Starting the NDIS Driver Setup Utility on
2. In the Channels section of the NDIS Driver Setup dialog
box, select the channel and click
(Status).
This channel status dialog box appears.
Figure 5-19. Channel Status Dialog Box
This dialog box displays channel status information and data
traffic counters. Information is refreshed every second. You
can open multiple occurrences of the channel status box for
multiple channels simultaneously.
To keep this window on top of other windows, click
(Keep on Top). Click the icon again to return the window to
its normal state.
