Firmware Management
154 Interphase Corporation
The Serial Line Properties dialog box appears.
Figure 9-5. Serial Line Properties
b. Specify the serial line clock, coding, and DSR timer
values that match the parameters of your X.25
provider.
c. Click OK to save the serial line properties and return
to the X.25 Protocol Properties dialog box.
7. Click OK to save the X.25 Protocol Properties
configuration and return to the WAN Adapters Setup
dialog box.
N
OTE
If you need to remove an X.25 network configuration,
select the configuration in the X.25 Protocol Properties
dialog box and press the Delete key.
8. Save the protocol changes on the adapter by reloading
the firmware as described in Saving WAN Adapters
Setup Properties on page 163 .
