Chapter 3: Connecting to the Line
iSPAN Serial WAN Adapter Users Guide
31
Figure 3-6. V.11 Cable Wiring
Adapter
side
DCE
side
Male DB25
connector
ISO4903
male DB15
connector
Drain wire
Braid
10
5
12
8
1
19
5
13
7
18
1
4
9
17
11
24
16
3
14
2
3
13
6
14
7
11
4
9
2
