www.gateway.com
89
External USB connectors
I
2
C (SMBus) connector
Additional specifications
For more information about your server, such as memory size, hard drive size, and processor
type, visit Gateway’s eSupport page at
support.gateway.com . The eSupport page also has links
to additional Gateway documentation and detailed specifications for your own server.
5 Keyboard (or mouse) clock
6 NC
Pin Signal Name
1 +5 V
2 USBN Data-
3 USBN Data+
4 GND
Pin Signal Name
1 I 2 C SCL
2 I
2
C SDA
3 I
2
C Alert
4 Ground
5 +3.3 V
Pin Signal Name
