APPENDIX A: Server Specifications
84
System specifications
System board specifications
Case size
(H×W×L)
1.70 Ч 15.79 Ч 29.58 inches (4.32 Ч 40.10 Ч 75.14 cm)
Weight 25 to 37 lbs. (11.34 to 16.78 Kg)
Fans ■ Six dual-rotor, multi-speed system fans
Ports ■ PS/2 keyboard or mouse (2)
■ USB (4 standard, 2 front and 2 back)
■ Serial
■ VGA (1 standard [back])
■ LAN (2) (RJ-45)
■ IPMI (RJ-45) for BMC
Drives
(standard)
One slimline drive bay for an optical drive
Hard drive bays Four SAS/SATA hot-swap hard drive bays
Card sizes Supports one full-length, full-height and one low-profile PCI expansion card
Power supply One 650 W hot-swap, power supply module (standard)
Additional 650 W hot-swap redundant power supply module (optional)
Operating
systems
Supports Windows Server 2003 (all), Windows Small Business Server 2003
(all), and Windows Storage Server 2003 (all)
Certifications ■ FCC Class A
■ UL
■ cUL
Processor Supports as many as two Intel® Xeon™ 5100 series processors
Chipset ■ Intel 5000P MCH (Northbridge)
■ Intel ESB2E (Southbridge)
Memory Eight 240-pin vertical DIMM slots support from 512 MB to 32 GB if
fully-buffered (FB-DIMM) DDR2-667 compliant, ECC, 72-bit, single rank or dual
rank, low-profile or ultra low-profile, SDRAM modules.
PCI device/slot PCI riser assembly, featuring:
■ One full-length, full-height 64-bit PCI-X 100 MHz or one PCI-Express riser,
which supports one card.
■ One low-profile (LP) PCI-Express riser, which supports one card.
VGA ■ Integrated Matrox G200 Graphics Core with 2.25 MB
■ Up to 1280 × 1024, 8 bpp or 1024 × 768, 16 bpp
Super I/O ■ Server Engine Pilot controller
■ Supports one fast UART 16550 serial port, one PS/2 keyboard port, and
one PS/2 mouse port
LAN ■ Intel ESB2 controller
■ Dual onboard 10/100/1000 network interface
■ IEEE 850.3u auto-negotiation support
■ Full duplex support
