www.gateway.com
87
Processor power connector (J6)
VGA connector
8 Power good
9 Stand by +5 V
10 +12 V
11 +12 V
12 +3.3 V
13 +3.3 V
14 -12 V
15 Ground
16 DC_ON (soft on/off)
17 Ground
18 Ground
19 Ground
20 Key
21 +5 V
22 +5 V
23 +5 V
24 Ground
Pin Signal Name
1 Ground
2 Ground
3 Ground
4 Ground
5 +12 V
6 +12 V
7 +12 V
8 +12 V
Pin Signal Name
1 Red (analog color signal R)
2 Green (analog color signal G)
Pin Signal Name
