15
3 Remove the bezel lock keys from the inside of the bezel, then insert the left side of the
bezel into the left handle and swing the right side of the bezel in until it snaps into place.
4 When the bezel is in place, lock the bezel by inserting the key into the lock in the lower
right corner of the bezel and turning it clockwise until it stops.
5 Put the key in a safe place.
Removing the server from a cabinet
To remove the server from a cabinet:
1 While supporting the server, remove the front and rear mounting screws that hold the
server in the cabinet.
2 Remove the server from the cabinet.
Warning
Screws are required to support the front and back of the server. You must
support the server while removing the front screws and back screws. If the server
is not supported, damage to the server or injury may result.
