Setting the system board jumpers 91
WOL Enable jumper
The WOL Enable jumper on the system board (jumper J5A2) lets you enable
the wake-on-LAN feature. (See the figure on page 8 for the location of the
jumper.)
The following table shows the settings required to perform this task. Make
sure you turn off the computer and unplug the power cord before moving
the jumper.
Mode Jumper
Setting Action When Set
Normal
Pins 9-10
Normal boot (default)
Update BMC
Pins 10-11
System updates BMC
Caution Moving the jumper while the power is on can damage the
server. Always turn off the server and unplug the power
cord before changing the jumper.
Mode Jumper
Setting Action When Set
Disabled
Pins 1-2
Disables wake-on-LAN
Enabled
Pins 2-3
Enables wake-on-LAN (default)
Caution Moving the jumper while the power is on can damage the
server. Always turn off the server and unplug the power
cord before changing the jumper.
