2 System Features
Front panel
Chassis lock that prevents unauthorized access to both the front panel
controls and to the interior of the system by locking the front bezel onto the
chassis.
Power LED that glows green whenever the system is turned on. The LED also
flashes when the system is in sleep mode.
Disk activity LED that glows green whenever any of the hard disks is actively
reading or writing data.
Reserved LED this LED is reserved for future use.
5.25” drive bay
5.25” drive bay
5.25” drive bay
CD drive
Diskette drive
Reserved
Hot-plug
drive bay
Front panel door
Chassis lock
Power LED
Disk activity LED
Reserved LED
Reset button
Power button
Hot-plug drive
activity LED
Hot-plug drive lock
Outriggers
Castors
PS 1 status LED
PS 2 status LED
Power supply
alarm speaker
reset
