Magnum 6K16V Managed Fiber Switch Installation and User Guide (01/04)
45
www GarrettCom com . .
The GBIC transceiver is fastened using snap-in clips. Insert the transceiver
(take care to insert it the right way up, arrows on top) until it clicks in space. While
removing the transceiver, press the clips on either side of the transceiver at the same time
and pull the transceiver out.
Each port has an Activity (ACT) LED indicating packets being received and a
Link (LK) LED indicating proper connectivity with the remote device when lit.
5.2.11 GBIC-LXSC Gigabit fiber (1000Mb), multi-mode SC Connector
The Magnum GBIC-LXSC is a single-mode Gigabit fiber connector equipped
with SC type connectors and can be easily snapped in and out. The Gigabit fiber ports are
most popular as server-to-switch and switch-to-switch applications. It supports cable
distances up to the IEEE 802.3z standard 1000Mbps distance limits, i.e., 10Km at full
duplex.
Each port has an Activity (ACT) LED indicating packets being received and a
link (LK) LED indicating proper connectivity with the remote device when lit.
5.2.12 6KM-BLNK
The 6KM-BLNK is a blank face plate or cover plate that must be installed in
any empty 6K16V PM slot to
maintain proper cooling air
flow, safety, etc.
Two screws
underneath the front panel hold
the 6KM-BLNK in place.
